BMC partner with real-time aero data tech developers Body Rocket

Body Rocket is the start up behind a device which gives real-time wind tunnel data to riders out on the road

The Brighton-based tech company Body Rocket is joining forces with Swiss bike brand BMC to refine its device which provides real-time drag measurements for cyclists.

2021 Body Rocket BMC 2

The partnership is said to provide Body Rocket development opportunities, by being able to refine and perfect the accuracy of its device on BMC bikes, while also giving BMC a performance insight into the link between its bikes and the athletes riding them.

Body Rocket says its technology will provide “accurately measured aerodynamics data for cyclists in real-time and in real conditions, on the road”—with this accuracy claimed to be within 0.3% of wind tunnel data.

Body Rocket put this video together when it was raising money for the project on CrowdCube last year (its target was £80,000 and it raised over £250,000) which briefly explains the concept.

From Body Rocket CrowdCube on Vimeo.

Unlike existing products which provide aerodynamic data using estimates to calculate drag, Body Rocket says that its patented aero system directly measures drag force and is said to use some of the same technology as wind tunnels.

2021 Body Rocket explainer 2

The system is fitted discreetly to the bike and consists of three sensors which are positioned on the stem, seat post and pedals, to constantly collect data.

Body Rocket says this gives a more complete picture of a cyclist’s aerodynamics than a wind tunnel because of the wider range of different wind conditions encountered.

With Body Rocket’s technology, riders are said to be able to make decisions about when and how to adjust positions to optimise their performance as conditions shift from headwinds to crosswinds.

2021 Body Rocket explainer

Using Garmin’s ConnectIQ platform, metrics like drag and wind direction/speed can be displayed on your GPS unit.

“With the body accounting for 80% of drag, empowering the rider with the ability to use live data to optimise their body performance tool,” says Body Rocket.

"After each session you will have a comprehensive picture of your aerodynamic data which you can analyse to identify incremental improvements."

The only other real-time drag measuring device we've used on is the Velocomp AeroPod.

The Body Rocket device should be available to buy at the end of 2021.

The initial product, which will include a power meter, is expected to launch at a price somewhere from £1,499 to £1,999.

Add new comment


Kelpie66 | 3 years ago

I am using velocomp aeropod, I get Live CDA windspeed values on my garmin using connectIQ and all that data is reported back on garmin, everything you have reported on

Nat Jas Moe | 3 years ago

Isn't this what Areopod does for a fraction of the price? Just asking.

rookybiker replied to Nat Jas Moe | 3 years ago

Yes. I find some of the claims made in the video to be doubtful. It is physically impossible, for example, to "directly" measure aerodrag of a moving object. It's always an indirect measurement. Such measurement can be quite accurate when using an extensive pressure rake (essentially an array of sensors measuring the momentum loss of the wake left behind) but this system, with so few pressure sensors, necessarily works the same way as Aeropod does: get power meter output, divide by ground speed, estimate and subtract rolling and drivetrain resistance, divide by the square of the measured airspeed and you have an estimate of CdA.

The claim of accuracy within 0.3% of a wind tunnel is nonsense. Even tunnels do not have that kind of accuracy, much less repeatability. Who are they kidding?

Body Rocket replied to rookybiker | 3 years ago

Body Rocket is different from all other devices.

It is unique because it is the only direct force drag meter and it is the only system that has been proven directly against wind tunnel measurements. Other products are indirect force systems that rely on a power meter reading and a number of estimates.

Body Rocket's three sensors on the bike collect all the data that is needed to calculate the rider's drag force in real time. This is quite different from the on-bike aero devices. They require estimates to be made of rolling resistance and drivetrain friction losses.
There are two problems with estimates.
The first is that they can be wrong.
The second is that forces being estimated can change during a ride.
Body Rocket is so accurate because it eliminates any need for estimates of those enigmatic and variable forces. Our sensors isolate the bicycle from the rider so its rolling resistance and drivetrain friction are removed entirely from the equation.
This leaves us with clean, estimate-free data about the rider's own aerodynamics.
No estimates, no guesstimates, consistent accuracy.

Body Rocket's technology is validated against the current gold standards. The wind tunnel is the gold standard for measuring aerodynamic drag force and we don't know of any way that is as accurate and repeatable. The University of Southampton has one of the best full scale wind tunnels in the UK.
