Is magnesium the bike material of the future?

New technology produces a material that’s extremely strong and lightweight

Could we all soon be riding bikes made from a new form of magnesium that’s exceptionally strong and lightweight?

A team from UCLA (University of California, Los Angeles) has produced a very strong new material with an extremely high stiffness-to-weight ratio by infusing magnesium with silicon carbide nanoparticles, according to an article in Nature

Magnesium is an abundant lightweight metal with a density about two-thirds that of aluminium. The trouble is that the magnesium alloys currently available lack the strength of other structural metals.

“Conventional synthesis and processing methods (alloying and thermomechanical processing) have reached certain limits in further improving the properties of magnesium and other metals,” says the UCLA team led by Xiao-Chun Li.

“Ceramic particles have been introduced into metal matrices to improve the strength of the metals, but unfortunately ceramic microparticles severely degrade the plasticity and machinability of metals, and nanoparticles, although they have the potential to improve strength while maintaining or even improving the plasticity of metals, are difficult to disperse uniformly in metal matrices.

“A dense uniform dispersion of silicon carbide nanoparticles (14 per cent by volume) in magnesium can be achieved through a nanoparticle self-stabilisation mechanism in molten metal. An enhancement of strength, stiffness, plasticity and high-temperature stability is simultaneously achieved, delivering a higher specific yield strength and higher specific modulus than almost all structural metals.

The new metal – actually a metal nanocomposite – has a very high specific strength and specific modulus – its strength-to-weight ratio. It has the potential to make lighter aircraft, spacecraft and cars, and perhaps has a future in the bicycle market too, although nobody yet knows the production costs.

Magnesium bikes are nothing new. The UK’s Kirk Precision started making magnesium frames back in the 1980s. These were cast in one piece rather than composed of jointed tubes.

Several other manufacturers have made magnesium bikes in the past too, including Pinarello and Merida. However, none of them have had access to this new material.

“The results we obtained so far are just scratching the surface of the hidden treasure for a new class of metals with revolutionary properties and functionalities,” said Xiao-Chun Li.

Could this herald a new age of high-end metal bikes? We'll be watching developments closely.

Mat has been in cycling media since 1996, on titles including BikeRadar, Total Bike, Total Mountain Bike, What Mountain Bike and Mountain Biking UK, and he has been editor of 220 Triathlon and Cycling Plus. Mat has been road.cc technical editor for over a decade, testing bikes, fettling the latest kit, and trying out the most up-to-the-minute clothing. We send him off around the world to get all the news from launches and shows too. He has won his category in Ironman UK 70.3 and finished on the podium in both marathons he has run. Mat is a Cambridge graduate who did a post-grad in magazine journalism, and he is a winner of the Cycling Media Award for Specialist Online Writer. Now over 50, he's riding road and gravel bikes most days for fun and fitness rather than training for competitions.

Add new comment

8 comments

Avatar
Arnon | 7 years ago
0 likes
Avatar
mike the bike | 8 years ago
0 likes

Crikey, this article is really spooky.  It was only the other day I was lounging on the sofa, battling bravely with a tube of Pringles, thinking to myself that if only we could infuse magnesium with silicon carbide nano-particles we could end up with a bike frame.  Assuming of course that we remembered to include a nano-particle self-stabilisation mechanism.  It just seemed so obvious.



Avatar
Gasman Jim | 8 years ago
0 likes

No!

Next question.

Avatar
JonD | 8 years ago
0 likes

I don't wish to be a spoilsport, but magnesium alloy of some sort has used for suspension fork lowers for some years..

Avatar
cqexbesd | 8 years ago
0 likes
Avatar
Leviathan | 8 years ago
1 like

Isn't Magnesium a bit flammable? Whoosh, Niki Lauda.



(bad taste, yes I know, I won't be swapping my carbon just yet.)

Avatar
hampstead_bandit | 8 years ago
0 likes

Magnesium bikes are nothing new. The UK’s Kirk Precision started making magnesium frames back in the 1980s. These were cast in one piece rather than composed of jointed tubes.



anyone that has worked in the bike industry for years will remember how that ended for Kirk  3

frames went "floppy" very quickly and cracked. after this became a widespread problem, it was realised that replacing the Kirk frame with another Kirk frame did not solve the issue, and customers were given welded tubular aluminium alloy frames

Avatar
hawkinspeter | 8 years ago
0 likes

Never mind magnesium, I want my 3d-printed graphene/carbyne/limpet tooth bike already.
