Is the front mech dying? Is there a future for the front derailleur on modern road bikes?

Single ring and wide-range cassette drivetrains are gaining popularity, so is this the end for the front mech?

First published November 4, 2017

With more and more sprockets on our wheels, do we still need two chainrings up front? We take a deep dive into the pros and cons of 1X gearing.

The drivetrain on a modern road bike has evolved loads since the early days when you turned a lever to move the chain to a different sprocket. Electronics are now commonplace and cassettes with ever-wider ranges provide enough gears to tackle even the steepest mountain climbs.

Most modern road bikes use two derailleurs to move the chain across the cassette and chainset, and it works well thanks to many years of product development. We probably take them for granted. But there's a move in some parts of the cycling world to simplify the drivetrain and it threatens the future existence of the front derailleur.

The arrival of SRAM’s 1x11 drivetrain a few years ago, a gear system that ditched the front mech and instead combined a single chainring with a wide-range cassette, provided another path. Such drivetrains have become hugely popular on mountain bikes and we've seen cyclocross and gravel bikes also being specced with single chainsets in recent years. Could the same happen to road bikes?

What are the benefits of 1X gearing?

The simplicity is certainly appealing. With just one shifter, changing gear is much more intuitive than having to manage the front and rear derailleurs. For beginners, that's an obvious benefit. There’s one less component to fail as well (though front derailleur failures are rare) and on bikes designed for wider tyres, removing the front derailleur can provide additional clearance around the rear wheel and seat tube area.

Read more: Beginner's guide: understanding gears

2021 Vitus Energie Evo - drivetrain.jpg

A short history of the front derailleur

Early users of double chainsets didn't even bother with front derailleurs; they pushed the chain from the large to small chainring with their heels at the bottom of a long climb, then stopped at the top of the hill to manually lift it back to the big ring. In the 1930s, French cycle tourists began using mechanisms to move the chain, as they realised being able to change gears was useful on the flat as well as when you had a long climb ahead.

Front derailleurs of the 1930s were usually actuated by cables; rod-operated front derailleurs appeared in the 1940s, and provided very quick and efficient shifts. You had to reach down towards the bottom bracket to operate them, which looks awkward to modern riders who are used to brake/shift levers, but was reportedly quite straightforward.

Read more: First Ride: SRAM 1x Road

Since then, the front derailleur really hasn't changed much at all. It's still a basic component, comprising two metal plates that shove the chain across the chainrings, and the stiffer those plates the better the shifting. But making plates stiffer by making them thicker also adds weight, so gear makers have added ramps and pins to the chainrings, bringing a real improvement in front shifting performance. The biggest recent development has been the addition of a motor in the electronic systems made by Shimano, Campagnolo, SRAM and FSA.

The 1x charge – the industry speaks

But the cycle industry is in a great period of technological development at the moment and everything is up for change. Chainsets have evolved from triples to doubles over the years with loads of configurations available, but a definite trend towards lower ratio setups like a compact, semi-compact and most recently, sub-compact. So if lower gears are popular, why not go all the way and use a smaller single ring?

For mountain biking, a single ring chainset makes a lot of sense. Changing gears is easier with just one gear shifter, there's one less thing to malfunction, mud and ground clearance is improved, weight is lowered and suspension designers are freed from the limitations of having to factor in a front derailleur when locating pivots. And any loss in gear range is compensated for by a wide-range cassette, with SRAM’s introduction of a 10-42t cassette and more recently 10-50t with its 12-speed Eagle groupset.

SRAM has been instrumental in the popularity of single ring drivetrains, but SRAM’s Global Drivetrain Category Manager Ron Ritzler doesn’t think fans of the front derailleur need to worry just yet.

"Will the front derailleur disappear? Probably not yet as there are certain users, like some elite athletes, who need the range and the steps to perform at their best – but can it kill the front derailleur for users who spend their time in cyclocross, commuting, adventure riding and in events where fast precise single ring performance is preferred; heck yes,” he tells us.

“We still make front derailleur and 2x rings that work really perfectly, but we love the fact that there are some many people using road bikes in new ways that make 1x the right choice."

While SRAM has been cheerleading the benefits of single ring drivetrains, Shimano isn’t really embracing it. Shimano’s Ben Hillsdon says the versatility of the double ring setup is just too good to ignore.

“Essentially the front derailleur doubles the number of gear ratios available to a rider, and, therefore, gives riders smaller steps in shifting between their biggest gear and their lowest gear,” he says. “That means riders have a wider range of gears, a smoother pedalling experience and their cadence (ie leg speed) can stay constant.

“That, in turn, brings a physiological benefit as muscles and joints are saved from being overworked, which can be crucial when it comes down to the sharp end of a race. The versatility of a double-ring setup is that you can go anywhere without compromise. However, for those riders choosing simplicity, our strategy is to offer drivetrains that can be set up in many different ways for different styles of riding.”

Read more: Your complete guide to SRAM road bike groupsets

2021 Shimano GRX Di2 groupset - drivetrain.jpg

Since we spoke to Ben Hillsdon, Shimano has backtracked a little though, introducing 1X options in the GRX range of gravel bike components. Okay, a gravel bike isn't a road bike, but there's no reason you couldn't use a gravel bike transmission on a road bike as long as you can get a top gear high enough for mountain descents and sprint finishes.

In fact, that's exactly what 3T have done with their Strada road bike, which now comes in a version with Campagnolo's 1X13 Ekar components. Ekar is intended for gravel bikes, but 3T clearly don't believe in discipline boundaries, and who's to say they're wrong?

2021 3t strada ekar 1x13 campagnolo edition

But a front derailleur gives you more gears, right?

One of the biggest advantages of the front derailleur was a big increase in the range of gears. That was an obvious advantage with a 5-speed cassette many decades ago. Over the years, the number of sprockets on the cassette has increased and is now up to 11, 12 or even 13.

Not only has the sprocket number increased, but the size of the sprockets has gone up: most racers predominantly used 12-23 cassettes a few years ago, but 11-30 is now common in the pro peloton and many sportive bikes now come with 11-34 cassettes.

Of course, removing one of the chainrings reduces your available range so to combat this SRAM introduced a whopping 10-42 cassette. It was instrumental in winning over mountain bikers as it was possible for a single ring drivetrain to offer nearly the same gear range as a conventional compact drivetrain.

Read more: SRAM Rival 1 review

How does a single ring drivetrain compare to a conventional drivetrain? Favourably, if you look at the numbers. Combine a 44-tooth single chainring with an 11-36 cassette and you have a gear range from 33 to 108 inches. That’s very nearly the same as the 32.8 to 122.7 range that a 50/34 and 11-28 setup provides, a setup many riders still use, though the latest off-the-peg bikes tend to have an 11-32 or 11-34 cassette.

You can adjust the size of the chainring and the cassette to tailor that gear range to suit the geography of your local terrain and riding style, whether solo touring rides or racing, much like you modify a current drivetrain with different chainsets and cassettes depending on whether you want top-end for racing or low-end for riding in the mountains.

While the gear range compares favourably, where the 1x setup falls short is in the jumps between the gears. This will concern those cyclists who like to be in the perfect gear for the optimum cadence at all times. How big a concern the larger jumps between gears will be to you depends largely on the type of cyclist you are, the sort of riding you do and your terrain. There is much work being done to provide cassettes that can help smooth the transition in the most frequently used gears, with 3T's Gerard Vroomen developing two versions of a 9-32t cassette that looks to be a good choice.

Kinesis Tripster AT - cassette.jpg

So should you ditch the front derailleur?

That depends. There are clear advantages and disadvantages to a 1X drivetrain at present. It’s unlikely we’ll see the front derailleur confined to the history books anytime soon, especially given Shimano’s dominant position in the market. That'll certainly be the case for regular road bikes and especially race bikes where tradition rules.

Where we're seeing single ring drivetrains really start to become a lot more popular is on bikes where the disadvantages are outweighed by the advantages offered by a simplified drivetrain, where the ultimate range isn't as critical and where the bigger jumps aren't as much of an issue.

Read more: Will your next bike be a gravel bike?

We’re talking about cyclocross bikes (where many racers have been going single ring for many years already with home-brewed solutions) and the gravel and adventure bike category where 1X is as common a transmission option as 2X. But with the likes of the 3T Strada and Whyte Wessex One, two road bikes designed around 1x11 drivetrains, we could be looking at more road bikes devoid of front derailleurs in the future.

Whyte Wessex One

Ultimately, though, the modern double-chainring transmission is too good for many cyclists to want to make a radical change. But the rise of wide-range cassettes does provide an interesting alternative that will appeal to many cyclists, which means we might see a few less front derailleurs on road bikes in the future.

Do you ride a bike with a single ring drivetrain?

David worked on the tech team from 2012-2020. Previously he was editor of and before that staff writer at RCUK. He's a seasoned cyclist of all disciplines, from road to mountain biking, touring to cyclo-cross, he only wishes he had time to ride them all. He's mildly competitive, though he'll never admit it, and is a frequent road racer but is too lazy to do really well. He currently resides in the Cotswolds, and you can now find him over on his own YouTube channel David Arthur - Just Ride Bikes
