Good quality one-inch components are getting scarcer but if Woodman’s Jupiter Aheadset is anything to go by, they're not about to disappear just yet. Weighing 156g, the Jupiter will suit anyone needing a bombproof headset and I can understand its popularity amongst the single speed fraternity. The unique, inverted crown race shields super smooth needle roller bearings from dirt and road srpay while O-ring seals complete the belt and braces weather protection.
I smothered everything in marine grease when I installed the headset but even without this most riders should enjoy long service intervals. Being alloy, the cups require careful installation so use the proper tools and don’t be tempted to improvise.
An expandable bung replaces the effective but fiddly star fangled nut. Ours needed a short bedding in period but after that never once rattled loose or left the front-end feeling sloppy. Such bungs are a great idea, and essential if using a carbon steerer, although I am not wholly convinced of their superiority to aftermarket headlock type systems.
Steering from the outset felt extremely refined, far surpassing that of units turning on loose balls. It's also available in standard inch and an eighth sizing which broadens the appeal to more contemporary markets including tourists and mountain bikers; it’s a shame there’s not an inch an a quarter option as the Jupiter’s ideal for tandem applications. The choice of black or silver anodizing means it won’t clash with existing colour schemes.
Slight weight penalty aside the Jupiter won’t disappoint anyone seeking a high quality replacement headset for older road, cyclocross and mountain bikes. A super smooth and well sealed headset ideal for bikes in hard service.
road.cc test report
Make and model: Woodman Jupiter aheadset 1
Size tested: 1"
Tell us what the product is for, and who it's aimed at. What do the manufacturers say about it? How does that compare to your own feelings about it?
The Jupiter is a CNC machined needle roller bearing headset with excellent weather sealing aimed at anyone needing a high end item. The importer advises they're particularly popular amongst the singlespeed fraternity.
Tell us some more about the technical aspects of the product?
The headset comprises of CNC machined alloy cups with inverted crown race defending against dirt and ingress, O-ring seals providing further protection to the needle roller bearings.
Might be a little on the hefty side for some.
Super smooth and dependable.
Pretty much what you'd expect to pay for a headset of this quality.
Tell us how the product performed overall when used for its designed purpose
Faultlessly, although bung type steerer required a little practice to set up correctly.
Tell us what you particularly liked about the product
Bullet proof build quality and super smooth bearings.
Tell us what you particularly disliked about the product
Did you enjoy using the product? Yes
Would you consider buying the product? Yes
Would you recommend the product to a friend? Yes
About the tester
I usually ride: Rough Stuff Tourer Based around 4130 Univega mtb Frameset My best bike is: 1955 Holdsworth Road Path and several others including cross & traditional road
I've been riding for: Over 20 years I ride: Most days I would class myself as: Experienced
I regularly do the following types of riding: cyclo cross, commuting, touring, fixed/singlespeed, mtb,
